Digital servo LV06 Chaservo MICRO (6g, 1.7kg.cm, 0.055s)
  • Digital servo LV06 Chaservo MICRO (6g, 1.7kg.cm, 0.055s)
  • Digital servo LV06 Chaservo MICRO (6g, 1.7kg.cm, 0.055s)
  • Digital servo LV06 Chaservo MICRO (6g, 1.7kg.cm, 0.055s)

Digital servo LV06 Chaservo MICRO (6g, 1.7kg.cm, 0.055s)

This powerful low-voltage servo offers the highest level of build quality and shows off its strengths with impressive precision. Wrapped in an elegant black aluminum bodice, the LV equivalent of our HV06 series packs an impressive punch.

Read more
€52.90
Quantity :
Stock available

  • Paiement sécurisé Paiement sécurisé
  • Livraison 24/48h Livraison 24/48h
  • Paiement 3X Paiement 3X
Cheaper elsewhere?

Features:

  • Extremely thin, 6 mm thick
  • Extremely light, only 6.1 g
  • Extremely fast and accurate
  • Highest manufacturing quality
  • Suitable for 1S, voltage range 3.5V - 5.0V
  • Available in three versions
  • High quality connection cable
  • Metal gears
  • Ideal for QR in the thinnest wings

SERVO DATA

  • Nominal voltage: 4.2 V DC
  • Voltage range: DC 3.3 V - 5.0 V
  • Standard magazine: ±60° = 120
  • Operating frequency: 1520µs/20KHz
  • Operating temperature : -10°C ... +65°C
  • Housing material: Aluminum alloy
  • Motor type: Coreless DC
  • Gear material: hardened steel
  • Position sensors: potentiometer
  • Programmable: Yes
  • Ball bearing: double ball bearing
  • 0.077 s/60 ° at 3.3 V
  • 0.066 s/60 ° at 4.2 V
  • 0.055 s/60 ° at 5.0 V
366-LV06
  • Thickness in mm (Servos) :
  • Torque in kg.cm (servos) : 1.7
  • Speed sec / 60° (servos) : 0.05
  • Pinions (servos) : Metal
  • Bearing (servos) : yes
  • Technology (sevos) : Digital
  • HV (servos) : no
  • Weight in g (servos) : 6
