ROXXY PROcontrol 155/8A S-BEC

Some details:

• High S-BEC (except OPTO HV)
• Additional connection cable to the receiver to minimize contact resistance and increase safety
• Easy programming with the optional ROXXY PROcontrol Programmer 02110
• Compatible with outrunner and inrunner motors running at high speed
• Soft start and linear throttle curve
• Motor Timing (advance) function for automatic timing
• Two different Governor modes can be selected in combination with a helicopter
• Equipped with high-efficiency MOSFET transistors, the drive is compact and lightweight, and its very low internal resistance allows for extremely high loads
• Generously dimensioned aluminum housing ensures good heat dissipation
• The high voltage types (HV OPTO) are equipped with an anti-arcing system.
  On other drive types, we recommend using a connector with anti-arcing system.

Technical data:

• Dimensions: 46 mm x 17 mm x 85 mm
• Weight: 0.130kg
• Continuous current: 125 A
• Number of cells: 2-6 LiPo, 5-18 NiMH
• BEC-Strom: 8 A
• Receiver Power supply : Yes
• Telemetry: No
• Brake type setting : off, soft, medium, hard
• Battery type selection : NiCd / NiMH, LiPo, LiFe
• Undervoltage threshold:
  - Li-xx: low (2.8 V per cell), medium (3.0 V per cell), high (3.2 V per cell), undervoltage cut-off disabled
  - Ni-xx: low (50% of initial voltage), medium (60% of initial voltage), high (65% of initial voltage)
• Timing:
  - Auto: the drive calculates the optimal timing automatically
  - 2°: for most internal rotor motors
  - 8°: for most internal rotor motors
  - 15°: for multipole motors (6 or more poles)
  - 22°: for multipole motors (6 or more poles)
  - 30°: for multipole motors
• S-BEC voltage selection (except OPTO HV)
  - Level 1: 5.0 V
  - Level 2: 6.0 V
  - Level 3: 7.4 V
  - Level 4: 8.4 V
• Activation of the speed control (helicopter): RPM off, Soft Start (& 2 Governor modes)
• Reversal of rotation direction
• Motor start selection on 9 levels
• Engine cut-off:
  - Reduce power, reduce engine speed.
  - Engine cut off.

Contents of the box:

(1) Roxxy PROcontrol
(1) Operating instructions
