Phoenix Model is proud to present the 90% pre-assembled NAVI PIPER J3 CUB GP/EP ARF. This aircraft is finely crafted from balsa and plywood and, as a result, has a fantastic flight. With materials of this quality, it's a model that flies very well. The Piper NAVI PIPER J3 CUB is a special version of the J3 Cub, built for the US Navy. Pilot and passenger sit one behind the other.
This model of the Piper Navy Cub impresses with its fine scale details and high-quality construction. Many parts have been 3D printed and hand-painted. The Piper Navy Cub can be fitted with either an electric or a combustion engine. A large side door provides easy access to the R/C installation and the flight battery or fuel tank.
The NAVI PIPER J3 CUB GP/EP ARF comes with a heat-sealed skin as shown here, and the fiberglass hood and cockpit are hand-painted to match. Wheels, fuel tank, engine mount and all accessories are included.
Flaps work for easy take-offs and landings. The NAVI PIPER J3 CUB GP/EP ARF is part of PHOENIX MODEL's comprehensive range of high-quality aircraft and accessories.
Technical data:
- Wingspan: 2300mm (90.5 in)
- Length: 1541mm (60.6 in)
- Flying weight: 6100-6500 g
- Wing area: 78 dm2
- Wing loading: 78.2 g/dm2
- Wing type: Naca airfoils
- Spinnaker size: ladder type (not included)
- Radio : 6 channels minimum (not included)
- Servo: 7 standard servo: 2 ailerons; 2 flaps; 1 elevator; 1 rudder; 1 throttle (not included)
- Recommended receiver battery: 6.0V 2400/2600mAh NiMH (not included)
- Servo support: 21mm x 42 mm
- Propeller: adapted to your engine
- Engine: 1.20 two-stroke incandescent engine / 20-26cc two-stroke petrol engine (not included)
- Motor: brushless outrunner 2000-2400 W, 450 KV (not included)
- Experience level: Intermediate
- Aircraft type: Civil to scale
- Two-piece wing - easy to assemble and transport.
- Anchoring points for mounting the scale float kit (sold separately) are already integrated into the fuselage.
- Quick-release fasteners, streamlined wing struts
RECOMMENDED MOTOR AND BATTERY CONFIGURATION:
- Motor: Rimfire 1.20 (not included)
- Propeller: 16x6 to 17x8 (not included)
- Lipo cell: 6S LiPo (not included)
- Esc: 80 Amp (not included)
