Advanced 10-channel telemetry receiver. It operates on a Twin 2.4GHz simultaneous dual-frequency transmission system. It features 10 high-precision PWM channels and 16 or 24 channel modes using S.BUS. Two detachable antennas with IPEX4 connectors deliver a full-power signal over a range of up to several tens of kilometers. It's particularly ideal for gliders, but you can also use it for a wide range of other models. With redundancy support, it can be connected as a primary receiver via S.BUS. Thanks to the Twin 2.4GHz protocol, both receivers operate simultaneously in this connection. Thanks to the F.BUS connection option, you can also link it quickly and easily to several different telemetry devices, providing bidirectional data transmission via a single cable.
It features advanced interference suppression for reliable, stable signal transmission over the entire range. Intelligent adaptation of the transmission system speeds up pairing. The black box function stores essential flight data. Receiver operating states are indicated by an LED. Intelligent pairing enables wireless firmware updates.
Help us to offer you the best price on the product "KAVAN R10 stabi receiver"
To help us improve your experience on our site, we are always interested in hearing from you!
And offering you the best possible price is one of our priorities, so if you find one of our products cheaper elsewhere on a competing European site, please let us know by filling in the form below.
The classic stabilizer mode has been extended with 5 additional stabilizer channels, providing pin mapping for each channel in several flight modes such as Stabilize, Auto-Level, Hover and Knife-Edge with model aircraft.
The advanced stabilization function includes high-precision telemetry sensors for monitoring altitude, vertical speed, etc.
In advanced stabilization mode, all output pins are configurable for stabilization and other advanced functions such as Stab file sharing, programmable parameters and developer access, etc.
Technical specifications :
RF transmission: Dual 2.4 GHz
Dimensions: 64×16.6×12.4 mm (L*W*H) 64×16.6×12.4 mm (L*W*H)
Weight: 9.4 g
Operating voltage: 3.5-12 V (recommended power supply 2S LiXX)
Operating current: ≤120 mA at 5 V
Vario - vertical speed measurement range: ±10 m/s
Vario - altimeter range and resolution: -700 m to 10,000 m, 0.1 m
External voltage measurement range via AIN2: 0-35 V
Antenna connector: IPEX4
Compatibility: Twin 2.4 GHz
Max. radiated power: < 20 dBm
Operating frequency: 2.400-2.4835 GHz
Features :
Enhanced protection against RF interference and more stable RF transmission
Twin 2.4GHz simultaneous transmission system with intelligent pairing
Advanced 10-channel telemetry receiver. It operates on a Twin 2.4GHz simultaneous dual-frequency transmission system. It features 10 high-precision PWM channels and 16 or 24 channel modes using S.BUS. Two detachable antennas with IPEX4 connectors deliver a full-power signal over a range of up to several tens of kilometers. It's particularly ideal for gliders, but you can also use it for a wide range of other models. With redundancy support, it can be connected as a primary receiver via S.BUS. Thanks to the Twin 2.4GHz protocol, both receivers operate simultaneously in this connection. Thanks to the F.BUS connection option, you can also link it quickly and easily to several different telemetry devices, providing bidirectional data transmission via a single cable.
It features advanced interference suppression for reliable, stable signal transmission over the entire range. Intelligent adaptation of the transmission system speeds up pairing. The black box function stores essential flight data. Receiver operating states are indicated by an LED. Intelligent pairing enables wireless firmware updates.
