Jeti Mezon evo 40 LMR controller
  • Jeti Mezon evo 40 LMR controller
  • Jeti Mezon evo 40 LMR controller

Jeti Mezon evo 40 LMR controller

LMR (Limited Motor Run) - the controller is specially designed for the lowest possible weight. This series is not in a metal box and is intended primarily for glider models where continuous motor run is limited to a few seconds followed by a controller cool down. The controller SW does not limit the operating time, it only monitors the maximum temperature to prevent the controller from being destroyed by overheating. It is the pilot's responsibility to ensure proper operation.

Read more
€139.90
Quantity :
Out-of-Stock

  • Paiement sécurisé Paiement sécurisé
  • Livraison 24/48h Livraison 24/48h
  • Paiement 3X Paiement 3X
Cheaper elsewhere?

Specifications:

  • full EX telemetry (voltage, current, capacity, revolution, etc.)
  • device configuration via EX Bus communication from the JETI Duplex transmitter
  • accurate governor and full support of helicopter models
  • F3A mode for aerobatic aircraft
  • adjustable brake with energy recovery in the accumulator
  • powerful BEC with adjustable output voltage
  • wide supply voltage range 2 - 12 Lixx (max. 51V)
  • bi-directional motor operation possible
  • active proportional brake
  • compact dimensions
  • user-friendly wizard for quick configuration of the controller ("Quick Setup mode")
  • in "expert mode", access to all controller programming options

Features :

  • Weight [g] 75
  • Dimensions [mm] 26 x 18 x 83
  • Sustained current [A] 40
  • Peak current (max 30s) [A] 40
  • Telemetry Yes
  • Operating temperature [°C] -10 to 85
  • Supply voltage [V] 6 to 51
  • LiXX batteries 2 to 12
  • Max. current [A BEC current [A] 15
  • BEC voltage [V] 5 to 8.4
  • Conductive resistance [mΩ] 1.9
  • Cable cross section (input/output) [mm²] 2.5 / 2.5
  • OPTO (radio signal optically separated from power management) No
  • Average current BEC [A] 15
  • Peak current BEC 1s [A] 30
  • Box Plastic tube
308-JME-040-B-LMR
